Function Description

1. Fully Automated Operation: The line features dual servo drive and full automatic operation, ensuring stable finished frame forming with a processing width range of 200–320mm.
2. High Production Capacity: It can process 30 frames per minute, with 40 pieces of 25 (30 and 40 Angle Steel function) and 500 pieces of L-shaped and U-shaped sheets produced per 8-hour shift, meeting high-volume production demands.
3. Compliance & Versatility: The production line meets 3C certification standards and supports various mold types, including square molding, copper pattern molding, and square shaft molding, to adapt to diverse damper frame specifications.

Basic Equipment

• Electric control system and motor decoiler
• Leveling device and punching big/small mouth die four sets
• Punching installation hole die one set and punching blade installation hole die one set
• TDF forming machine, main oil pressure forming machine one set, and hydraulic bending device one set
• Numerical control system, PLC one set, and feeding platform one set
